lowering the triple

so...since i changed to the E07 tyres the front end is light and over 80mph there is a small wobble.
i think it might be because the geometry of the bike changed (taller tyre) as well as bar risers that shifted some of my weight slightly back.

so im thinking of lowering the triple by 5mm or less but i have one concern is there enough clearance so it doesnt hit if i bottom out.
if anyone did anything similar to this let me know.

all advice would be appreciated

2014 vee2- OEM:skid plate,heated grips,mirror extenders,centerstand. aftermarket:sw-motech: risers,trax 45L side cases 38L top case,pipe valve guard, kickstand foot enlarger. corbin/holshot heated seat ,MRA VarioTouringScreen,burkbusters storm,PC8, kaoko throttle lock, scorpion titanium slip-on, denali airbomb,scottoiler,denalli dx.pc5+autotune R&G:radiator guard, pipe slider K&N:air filter touratech:crashbars, ABS kill switch,dryspec tool tube,cyclops LED headlights,doubleback mirrors,helmet guardian,twowheels shorty levers,aftermarket off road rear brake lever,shorai lithium battery.
alon is offline
Sponsored Links
Advertisement

post #2 of 17 Old 05-04-2017, 06:33 PM
Stromthusiast!

Join Date: Oct 2014
Location: Massachusetts
Posts: 528
Generally, lowering the front has the effect of decreasing rake, which lessens stability. That is why cruisers are more stable than sport bikes.
I have the E07's (about 1500 miles so far) on my vee2 and I've had it up to about 90mph and have not noticed any wobble. Are you sure they are balanced? Might want to try putting in some Ride-on.
Also, it would be easier to play around with pre-load to change the front-to-rear angle to see if it makes a difference.

2014 DL650 (sold)
2014 DL1000
mcrag is offline
post #3 of 17 Old 05-04-2017, 06:40 PM Thread Starter
Stromthusiast!

alon's Avatar

Join Date: Jul 2010
Location: NYC
Posts: 495
Garage
well i had them balanced when i got them mounted (i have about 2500 miles on them by now ).
why would ride on help?

2014 vee2- OEM:skid plate,heated grips,mirror extenders,centerstand. aftermarket:sw-motech: risers,trax 45L side cases 38L top case,pipe valve guard, kickstand foot enlarger. corbin/holshot heated seat ,MRA VarioTouringScreen,burkbusters storm,PC8, kaoko throttle lock, scorpion titanium slip-on, denali airbomb,scottoiler,denalli dx.pc5+autotune R&G:radiator guard, pipe slider K&N:air filter touratech:crashbars, ABS kill switch,dryspec tool tube,cyclops LED headlights,doubleback mirrors,helmet guardian,twowheels shorty levers,aftermarket off road rear brake lever,shorai lithium battery.
alon is offline

post #4 of 17 Old 05-04-2017, 10:03 PM
Stromthusiast!

Join Date: Oct 2014
Location: Massachusetts
Posts: 528
RideOn would only help if they weren't balanced.

2014 DL650 (sold)
2014 DL1000
mcrag is offline
post #5 of 17 Old 05-04-2017, 10:49 PM
Stromthusiast!

Join Date: Mar 2011
Location: Pasadna area
Posts: 13,892
Seems to me I've read that the Wee is kinda inherently unstable over 90.
Someone correct me if I'm wrong.
notacop is offline
post #6 of 17 Old 05-04-2017, 11:30 PM
Stromthusiast!

NVDucati's Avatar

Join Date: Sep 2015
Location: Northern Calif
Posts: 928
Quote:
Originally Posted by alon View Post
so im thinking of lowering the triple by 5mm or less but i have one concern is there enough clearance so it doesnt hit if i bottom out.
if anyone did anything similar to this let me know.

all advice would be appreciated
To answer your question as asked: I have a V2 and have slid the triple tree down to the where the taper begins. No bottoming and believe that if it was going to , it would have. I think that taper is not located by accident.

AS for your slight wobble: If it is balanced / it is balanced. However, if it is balanced but the tire isn't centered on the rim ... I don't know those particular tires but they likely have a mold ring that you can look at. Some times tires aren't round enough. I know that Avon will replace a tire no questions asked if you can't get it mounted to satisfaction. Others likely will, too. Otherwise remove and carefully reinstall the wheel again. Then you have your basics done and can chase all the theories.
alon likes this.

Member: AMA
Current Rides: '14 DL1000 ADV, '06 SV650N, '93 900CBRR, '74 Ducati 750GT ['02 BMW K1200rs SOLD Aug '17]
NVDucati is offline
post #7 of 17 Old 05-05-2017, 10:56 AM Thread Starter
Stromthusiast!

alon's Avatar

Join Date: Jul 2010
Location: NYC
Posts: 495
Garage
Quote:
Originally Posted by NVDucati View Post
To answer your question as asked: I have a V2 and have slid the triple tree down to the where the taper begins. No bottoming and believe that if it was going to , it would have. I think that taper is not located by accident.

AS for your slight wobble: If it is balanced / it is balanced. However, if it is balanced but the tire isn't centered on the rim ... I don't know those particular tires but they likely have a mold ring that you can look at. Some times tires aren't round enough. I know that Avon will replace a tire no questions asked if you can't get it mounted to satisfaction. Others likely will, too. Otherwise remove and carefully reinstall the wheel again. Then you have your basics done and can chase all the theories.
thanks thats what i wanted to know...busy the next 2 weekends but i will try after

2014 vee2- OEM:skid plate,heated grips,mirror extenders,centerstand. aftermarket:sw-motech: risers,trax 45L side cases 38L top case,pipe valve guard, kickstand foot enlarger. corbin/holshot heated seat ,MRA VarioTouringScreen,burkbusters storm,PC8, kaoko throttle lock, scorpion titanium slip-on, denali airbomb,scottoiler,denalli dx.pc5+autotune R&G:radiator guard, pipe slider K&N:air filter touratech:crashbars, ABS kill switch,dryspec tool tube,cyclops LED headlights,doubleback mirrors,helmet guardian,twowheels shorty levers,aftermarket off road rear brake lever,shorai lithium battery.
alon is offline
post #8 of 17 Old 05-07-2017, 12:57 AM
Stromthusiast!

OregonMike's Avatar

Join Date: Apr 2017
Location: Oregon
Posts: 242
5mm... WOW. I dropped the TLR by about 1.5-2 and GSX-R by 1.5 and they got sketchy... but cuts through corners like a razor knife...

OregonMike is offline
post #9 of 17 Old 05-07-2017, 10:28 AM
Stromthusiast!

Forseti's Avatar

Join Date: Dec 2006
Location: Near Kingston Ontario Canada
Posts: 475
I have E07's on my 14 1000... no indication of wobble at speed. The only issue I've had is the lack of fender clearance on the front.
Forseti is offline
post #10 of 17 Old 05-08-2017, 12:58 PM Thread Starter
Stromthusiast!

alon's Avatar

Join Date: Jul 2010
Location: NYC
Posts: 495
Garage
so talked to Yuval

and he suggested to lower the front's air pressure to 33psi instead of 36 like suzuki recommends(with the stock tires) did that rode from nyc to philly about 250miles in total speeds up to 105mph(just to check) steady as a rock even though it was windy as hell.

front is still light but i think i just have to adjust my suspension
